Sleep-Wake_Regulation-Model 01_01

globals [
          fc-network
          mc-network
          pc-network
          lc-network
          vlpo-network
          th-network
          dr-network
          ldt-ppt-network
          ox-network

          sleep-propencity?
          main-patches
          edge-patches
          ]

breed [fc-neurons fc-neuron]
breed [mc-neurons mc-neuron]
breed [pc-neurons pc-neuron]
breed [lc-neurons lc-neuron]
breed [vlpo-neurons vlpo-neuron]
breed [th-neurons th-neuron]
breed [dr-neurons dr-neuron]
breed [ldt-ppt-neurons ldt-ppt-neuron]
breed [ox-neurons ox-neuron]

breed [nodes node]
breed [impulses impulse]
breed [spinners spinner]

undirected-link-breed [rf-links rf-link]
undirected-link-breed [slinks slink]
directed-link-breed [red-links red-link]
directed-link-breed [green-links green-link]

patches-own [ adenozin ]
impulses-own [location]

to setup

 clear-turtles
 clear-patches
 clear-links
 clear-all-plots
 clear-drawing

 import-drawing "Sleep-Wake_Regulation-M01_01.png"

 create-fc-network
 create-mc-network
 create-pc-network
 create-lc-network
 create-vlpo-network
 create-th-network
 create-dr-network
 create-ldt-ppt-network
 create-ox-network
 create-spinner

 ask turtles [ set adenozin random 0.1 ]
 recolor-patches

 ask patches at-points [[7 -11] [0 0] [2 3] [2 -16] [8 -21]]
  [ sprout-nodes 1
    [
    set shape "circle"
    set size 3
     ht
    ]
  ]

  ask nodes [
    create-rf-link-with one-of other nodes
  ]

  create-impulses 5 [
    set shape "circle"
    set size 1
    set color yellow
    set location one-of nodes
    move-to location
  ]
  set edge-patches patches with [count neighbors != 8]
  set main-patches patches with [count neighbors = 8]

   ask spinners [setxy -40 -40]

   reset-ticks
end

to create-fc-network
   create-fc-neurons  20 [
      set shape "circle"
      set color yellow
    set size 1.5
  ]
  set fc-network patches with [
        pxcor > ( - 38 ) and
        pxcor <  ( - 27 ) and
        pycor > 0 and
        pycor < 27
      ]

  ask fc-neurons [move-to one-of fc-network
  ]
end

to create-mc-network
   create-mc-neurons  30 [
      set shape "circle"
      set color yellow
    set size 1.5
  ]
  ask one-of mc-neurons [ set label "Cortex" ]

  set mc-network patches with [
        pxcor > ( - 20 ) and
        pxcor < 20 and
        pycor > 20 and
        pycor < 37
      ]


   ask mc-neurons [move-to one-of mc-network]
end

to create-pc-network
   create-pc-neurons  40 [
      set shape "circle"
      set color yellow
    set size 1.5
  ]

  set pc-network patches with [
        pxcor > 18 and
        pxcor < 38 and
        pycor > ( - 2) and
        pycor < 24
      ]

   ask pc-neurons [move-to one-of pc-network]
end

to create-lc-network
   create-lc-neurons 1 [
      set shape "elipce"
      set color violet
      set size 7
      set heading (- 10)
      set label "LC"
  ]

  set lc-network patches with [
        pxcor >  6  and
        pxcor < 9 and
        pycor > ( - 20 ) and
        pycor < ( - 18)
      ]

   ask lc-neurons [move-to one-of lc-network]
end

to create-vlpo-network
      create-vlpo-neurons 2 [
      set shape "circle"
      set color green
      set size 3
     ]
     ask one-of vlpo-neurons [ set label "VLPO" ]

  set vlpo-network patches with [
        pxcor > ( - 8 ) and
        pxcor < ( - 6 ) and
        pycor > ( - 5 ) and
        pycor < 0
      ]

   ask vlpo-neurons [move-to one-of vlpo-network]
end

to create-th-network
   create-th-neurons 7 [
      set shape "circle"
      set color orange
    set size 2
  ]
   ask one-of th-neurons [ set label "Thalamus" ]

  set th-network patches with [
        pxcor > ( - 6 ) and
        pxcor < 8 and
        pycor > 2 and
        pycor < 12
      ]

   ask th-neurons [move-to one-of th-network]
end

to create-dr-network
   create-dr-neurons  1 [
      set shape "circle"
      set color magenta
      set size 2.5
      set label "DR"
     ]
  set dr-network patches with [
        pxcor > 1 and
        pxcor <  3 and
        pycor > (-17) and
        pycor < (-15 )
      ]

  ask dr-neurons [ move-to one-of dr-network ]
end

to create-ldt-ppt-network
   create-ldt-ppt-neurons  1 [
      set shape "circle"
      set color pink
      set size 2.5
      set label "LDT/PPT"
     ]
  set ldt-ppt-network patches with [
        pxcor > 6 and
        pxcor <  8 and
        pycor > ( - 12 ) and
        pycor < ( - 10 )
      ]

  ask ldt-ppt-neurons [move-to one-of ldt-ppt-network
  ]
end

to create-ox-network
   create-ox-neurons 3
   [
    set shape "pentagon"
    set color yellow
    set size 2
    set label "Orexin"
  ]
  set ox-network patches with [
        pxcor > 1 and
        pxcor < 2 and
        pycor > 3 and
        pycor < 4
      ]
end

to go

  cycle-s-propencity
  diffuse adenozin 0.7
  recolor-patches
  update-spinner
  tick
end

to run-wake-state

   if not any? fc-neurons [stop]
   ask one-of fc-neurons [
    create-slink-with one-of other fc-neurons
  ]
  while [ count slinks > 30 ]
  [ ask one-of slinks [ die ]
  ]

    if not any? mc-neurons [stop]
   ask one-of mc-neurons [
    create-slink-with one-of other mc-neurons
  ]
  while [ count slinks > 50 ]
  [ ask one-of slinks [ die ]
  ]

    if not any? pc-neurons [stop]
   ask one-of pc-neurons [
    create-slink-with one-of other pc-neurons
  ]
  while [ count slinks > 60 ]
  [ ask one-of slinks [ die ]
  ]

   if not any? th-neurons [stop]
   ask one-of th-neurons [
    create-slink-with one-of other th-neurons
  ]
  while [ count slinks > 15 ]
  [ ask one-of slinks [ die ]
  ]

   ask one-of th-neurons [
    create-red-link-to one-of pc-neurons
       ]
  ask red-links [
    set color red
    set thickness 0.2
  ]

  while [ count red-links > 3 ]
  [ ask one-of red-links [ die ]
  ]
   ask one-of th-neurons [
  create-red-link-to one-of mc-neurons
       ]
  ask red-links [
    set color red
    set thickness 0.2
  ]

  while [ count red-links > 3 ]
  [ ask one-of red-links [ die ]
  ]
    ask one-of th-neurons [
    create-red-link-to one-of fc-neurons
       ]
    ask red-links [
    set color red
    set thickness 0.2
  ]

  while [ count red-links > 3 ]
  [ ask one-of red-links [ die ]
  ]

  ask green-links [die]

  ask turtles [
    set adenozin random 0.1 + 0.5  ]

  ask rf-links [ set thickness 0
                 set color yellow]
  ask impulses [
                 let new-location one-of [rf-link-neighbors] of location
                 ask [rf-link-with new-location] of location [ set thickness 1 ]
                 face new-location
                 move-to new-location
                 set location new-location
               ]

 if (scenario = "Normal") and ( round sum [adenozin] of patches ) >= 1000
    [ set sleep-propencity? true]

 if (scenario = "Sleep-deprivation") and (( round sum [adenozin] of patches ) >= 1500)
    [ set sleep-propencity? true
      set scenario  "Normal" ]
end

to recolor-patches

  ask patches [ set pcolor scale-color red adenozin 0 1 ]
end

to run-sleep-state

  ask turtles [set adenozin adenozin - 0.2]
  ask impulses [stop]

  ask rf-links [set thickness 0]
  ask slinks [die]
  ask red-links [die]

  if not any? vlpo-neurons [stop]
  ask one-of vlpo-neurons [
  create-green-link-to one-of lc-neurons
  ]

  ask one-of vlpo-neurons [
                           create-green-link-to one-of DR-neurons
                          ]

  ask one-of vlpo-neurons [
                           create-green-link-to one-of ldt-ppt-neurons
                          ]

  ask one-of vlpo-neurons [
                           create-green-link-to one-of ox-neurons
                          ]

    ask green-links [
    set color green
    set thickness 0.7 ]
    while [ count green-links > 3 ]
    [ ask one-of green-links [ die ]
    ]

  ask edge-patches [ set adenozin 0 ]
  repeat 100 [ ask edge-patches [ set adenozin 0 ]]
  ifelse round sum [adenozin] of patches <= 0
  [set sleep-propencity? false]
  [set sleep-propencity? true]
end

to cycle-s-propencity
   ifelse (sleep-propencity? = false) [
    run-wake-state
  ][
    run-sleep-state
  ]
end

to create-spinner
  create-spinners 1 [
    set shape "clock"
    set color gray - 1.5
    set size 15
    set heading -0
    set label 0
    set label-color green
    ]
end

to update-spinner
    ask spinners [
    set heading ticks * 10
    set label ticks
    set adenozin adenozin - 0.3
  ]
end
