Comparing explanatory power and explanatory goodness

breed [power-seekers power-seeker]
breed [goodness-seekers goodness-seeker]


turtles-own [
  count-h1 ; number of times h1 is better than h2
  count-h2 ; number of times h2 is better than h1
  prior-h1 ; prior credence in h1
  prior-h2 ; prior credence in h1
  prop-h1 ; credence that h1 is the best explanation
  prop-h2 ; credence that h2 is the best explanation
  strategy ; update strategy
  truth-alignment ; tracks whether the agent aligns with the ground truth
  k1 ; variable to make calculations of EG_1 and EG_2 simpler
  k2 ; variable to make calculations of EG_1 and EG_2 simpler
  EP_1 ; value of power for h1
  EP_2 ; value of power for h2
  EG_1 ; value of goodness for h1
  EG_2 ; value of goodness for h2
  preferred-hypothesis ; truth-alignment variable
]


patches-own [
  likelihood-h1 ; represents strength of evidence for h2 on this patch – i.e., P(e|h1)
  likelihood-h2 ; represents strength of evidence for h2 on this patch – i.e., P(e|h2)
]


; initialize the world

to setup
  clear-all
  setup-patches
  setup-turtles
  reset-ticks
end


; create evidence patches

to setup-patches
  ask patches [
    set likelihood-h1 max list 0 min list 1 (random-normal avg-likelihood-h1 0.2)   ; each patch has P(e|h1) between 0.001 and the number assigned by the slider
    if likelihood-h1 < 0.0001 [ set likelihood-h1 0.001 ] ; ensures NetLogo doesn't go crazy with logarithms of small numbers

    set likelihood-h2 max list 0 min list 1 (random-normal avg-likelihood-h2 0.2)  ; each patch has P(e|h2) between 0.001 and the number assigned by the slider
    if likelihood-h2 < 0.001 [ set likelihood-h2 0.001 ] ; ensures NetLogo's doesn't go crazy with logarithms of small numbers

    ; calculate set color based on the dominant likelihood
    let likelihood-diff likelihood-h1 - likelihood-h2
    if likelihood-diff > 1 [
      set pcolor scale-color green likelihood-diff 0 1  ; darker green as likelihood-diff increases
    ]
    if likelihood-diff < 1 [
      set pcolor scale-color green (1 - likelihood-diff) 0 1  ; lighter green as likelihood-diff decreases
    ]
    if likelihood-diff = 0 [
      set pcolor green  ; set to pure green when the likelihoods are the same
    ]
  ]
end

; create agents

to setup-turtles

  create-power-seekers number-of-turtles-each [
    set color red
    set  count-h1 0
    set  count-h2 0
    set  prop-h1 0
    set  prop-h2 0
    set prior-h1 max list 0 min list 1 (random-normal avg-prior-h1-power-seekers sd-priors-ps)
    if prior-h1 > 1 [set prior-h1 1]
    set  prior-h2 (1 - prior-h1)
    if prior-h1 > 1 [set prior-h1 1]
      set strategy "power"
      setxy random-xcor random-ycor
  ]

  create-goodness-seekers number-of-turtles-each [
    set color blue
    set  count-h1 0
    set  count-h2 0
    set  prop-h1 0
    set  prop-h2 0
    set prior-h1 max list 0 min list 1 (random-normal avg-prior-h1-goodness-seekers sd-priors-gs)
    if prior-h1 > 1 [set prior-h1 1]
    set  prior-h2 (1 - prior-h1)
    if prior-h1 > 1 [set prior-h1 1]
    set strategy "goodness" ; strategy type
    setxy random-xcor random-ycor ; place them randomly in the world
  ]
end


; main update loop

to go
  ask turtles [
    move
    update
  ]
  update-plot
  update-plot1
  update-histogram
  update-disagreement-plot
  if ticks = 100 [ stop ] ;stopping condition
  tick
end


; turtles move randomly

to move
  rt random 360
  fd 1
end

;;;;;;;;;;;;;;;;;;;STRATEGIES;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

; set strategies

to update
  let evidence-here-h1 [likelihood-h1] of patch-here
  let evidence-here-h2 [likelihood-h2] of patch-here

;print (word "Likelihoods: likelihood-h1=" evidence-here-h1 " likelihood-h2=" evidence-here-h2)

  if strategy = "power" [ ;power-seekers strategy
    let P_e (evidence-here-h1 * prior-h1 + evidence-here-h2 * prior-h2) ; computes P(e) using the rule of total probability

    set EP_1 (log evidence-here-h1 10) - (log P_e 10) ;explanatory power for h_1
    set EP_2 (log evidence-here-h2 10) - (log P_e 10) ;explanatory power for h_2

    if EP_1 > EP_2 [set count-h1 count-h1 + 1] ;comparison procedure
    if EP_2 > EP_1 [set count-h2 count-h2 + 1] ;comparison procedure

    if p-s-bayes-updating? [ ;updating procedure
      set prior-h1 (evidence-here-h1 * prior-h1 / P_e) ; updating P(h1)
      set prior-h2 (evidence-here-h2 * prior-h2 / P_e) ; updating P(h2)
      if prior-h1 > 1 [set prior-h1 1] ; to avoid anomalous priors
      if prior-h2 > 1 [set prior-h2 1] ; to avoid anomalous priors
    ]

    ifelse (count-h1 + count-h2) > 0 [ ;ensures NetLogo will be able to calculate the fraction below
      set prop-h1 (count-h1 / (count-h1 + count-h2)) ; prop. h1 is the best
      set prop-h2 (count-h2 / (count-h1 + count-h2)) ; prop. h2 is the best
      set prop-h1 max list 0 min list 1 prop-h1 ; clamp values
      set prop-h2 max list 0 min list 1 prop-h2 ; clamp values
    ] [
      set prop-h1 0
      set prop-h2 0
    ]

    ; truth-alignment procedure for power-seekers
    set preferred-hypothesis ifelse-value (EP_1 > EP_2) ["h1"] ["h2"] ;picks out the selected hypothesis
    ifelse preferred-hypothesis = ground-truth [set truth-alignment truth-alignment + 1] [set truth-alignment truth-alignment - 1] ;truth alignment counting
    if truth-alignment > ticks [set truth-alignment ticks]  ; clamp values
  ]

  if strategy = "goodness" [;goodness-seekers strategy
    let P_e (evidence-here-h1 * prior-h1 + evidence-here-h2 * prior-h2); computes P(e) using the rule of total probability

    ifelse prior-h1 < (10 ^ -300) [set k1 -300] [set k1 log prior-h1 10] ; k1 facilitates NetLogo's handling the log of very low numbers
    ifelse prior-h2 < (10 ^ -300) [set k2 -300] [set k2 log prior-h2 10]; k1 facilitates NetLogo's handling the log of very low numbers

    set EG_1 (log evidence-here-h1 10) - log P_e 10 + (0.5 * k1) ; explanatory goodness for h1
    set EG_2 (log evidence-here-h2 10) - log P_e 10 + (0.5 * k2) ; explanatory goodness for h2

    if EG_1 > EG_2 [set count-h1 count-h1 + 1] ;comparison procedure
    if EG_2 > EG_1 [set count-h2 count-h2 + 1] ;comparison procedure

    if g-s-bayes-updating? [ ;updating procedure
      set prior-h1 (evidence-here-h1 * prior-h1 / P_e) ; updating P(h1)
      set prior-h2 (evidence-here-h2 * prior-h2 / P_e) ; updating P(h2)
      if prior-h1 > 1 [set prior-h1 1] ; to avoid anomalous priors
      if prior-h2 > 1 [set prior-h2 1] ; to avoid anomalous priors
    ]


    ifelse (count-h1 + count-h2) > 0 [ ;ensures NetLogo will be able to calculate the fraction below
      set prop-h1 (count-h1 / (count-h1 + count-h2)) ; prop. h1 is the best
      set prop-h2 (count-h2 / (count-h1 + count-h2)) ; prop. h2 is the best
      set prop-h1 max list 0 min list 1 prop-h1  ; clamp values
      set prop-h2 max list 0 min list 1 prop-h2  ; clamp values
    ] [
      set prop-h1 0
      set prop-h2 0
    ]

  ; truth-alignment procedure for goodness-seekers
  set preferred-hypothesis ifelse-value (EG_1 > EG_2) ["h1"] ["h2"] ;picks out the selected hypothesis
  ifelse preferred-hypothesis = ground-truth [set truth-alignment truth-alignment + 1] [set truth-alignment truth-alignment - 1] ;truth alignment counting
  if truth-alignment > ticks [set truth-alignment ticks]  ; clamp values

  ]
end


;;;;;;;;;;;;;PLOTS;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

; update plot for prop(h1)

to update-plot
  set-current-plot "Average Proportion h1 is the Best over Time"

  set-current-plot-pen "Power-Seekers"
  plotxy ticks mean [prop-h1] of power-seekers

  set-current-plot-pen "Goodness-Seekers"
  plotxy ticks mean [prop-h1] of goodness-seekers
end

; display results: average credence over time for both groups

to plot-results
  set-current-plot "Average Proportion h1 is the Best over Time"

  set-current-plot-pen "Power-Seekers"
  plotxy ticks mean [prop-h1] of power-seekers

  set-current-plot-pen "Goodness-Seekers"
  plotxy ticks mean [prop-h1] of goodness-seekers
end

; update truth-alignment plot

to update-plot1
  set-current-plot "Truth Alignment Over Time"

  set-current-plot-pen "Power-Seekers"
  plotxy ticks mean [truth-alignment] of power-seekers

  set-current-plot-pen "Goodness-Seekers"
  plotxy ticks mean [truth-alignment] of goodness-seekers
end

; display results: truth alignment over time for both groups

to plot-results1
  set-current-plot "Truth Alignment Over Time"

  set-current-plot-pen "Power-Seekers"
  plotxy ticks mean [truth-alignment] of power-seekers

  set-current-plot-pen "Goodness-Seekers"
  plotxy ticks mean [truth-alignment] of goodness-seekers
end

; update priors distribution histogram

to update-histogram
  set-current-plot "Prior Distributions"
  clear-plot
  set-current-plot-pen "Distribution h1 PS"
  histogram [prior-h1] of power-seekers
  set-current-plot-pen "Distribution h1 GS"
  histogram [prior-h1] of goodness-seekers
end

; update disagreement plot

to update-disagreement-plot
  set-current-plot "Disagreement on the BE over Time"

  set-current-plot-pen "Power-Seekers"
  plotxy ticks standard-deviation [prop-h1] of power-seekers

  set-current-plot-pen "Goodness-Seekers"
  plotxy ticks standard-deviation [prop-h1] of goodness-seekers
end



;##################################################################################################
